Item
|
Parameters
|
|
|
|
Basic indicators
|
Rate power
|
120kw
|
|
|
Model
|
120k
|
|
|
Cable current
|
CCS2:200A
|
CHdeMO:125A
|
|
Heat-disspating method
|
Forced air cooling
|
|
|
Network Type
|
Ethernet/4G
|
|
|
Operating environment
|
Indoor or outdoor (IP54)
|
|
|
Display mode
|
12-inch Screen for streaming media
|
|
|
Dimensions (W x d x H)
|
800mm x 610mm x 1880mm
|
|
|
Weight（kg)
|
330
|
|
|
Others
|
Streaming media,aerosol extinguishing equipment,flood alarm(customizable)
|
|
|
Communication
|
Communication mode
|
PLC(DIN 7121:2014-12/ISO15118)
|
|
|
Communication protocol
|
OCPP1.6
|
|
|
Method of payment
|
Method of payment
|
Credit card,Unionpay card, WeChat,Alipay,M1 card (Customizable)
|
|
|
Input characteristics
|
Input voltage
|
380VAC±15%，three-phase+N+PE
|
|
|
Frequency
|
50±1Hz
|
|
|
Rated input current
|
193A
|
|
|
Power factor
|
≥0.99
|
|
|
ITHD
|
≤5%
|
|
|
Output characteristics
|
Voltage range
|
100——1000VDC（Constant power range300-1000VDC)
|
100——500VDC（Constant power range300-500VDC)
|
|
Maximum current
|
200A
|
125A
|
|
Maximum output power
|
120kw
|
60KW
|
|
Charging strategy
|
Round charging and even charging
|
|
|
Peak efficiency
|
≥95%
|
|
|
Output voltage error
|
≤±0.5%
|
|
|
Output current error
|
≥30A，≤±1%，＜30A，≤±0.3A
|
|
|
Voltage stabilized accuracy
|
≤±0.5%
|
|
|
Current stabilized accuracy
|
≤±1%
|
|
|
Ripple voltage peak value coefficent
|
≤±1%
|
|
|
Environmental indicators
|
Operating temperature
|
-25℃~50℃
|
|
|
Storage Temperature
|
-40℃~+80℃
|
|
|
Relative humidity
|
5~90%RH，non-condensing
|
|
|
Operational altitude
|
2000m No derating required＞2000m,the working temperature decreases by 1℃ for every 100m rise
|
|
Advantage
Harsh environmentExcellent performance at high temperature with wide constant power range byusingUXRmoduleCharging efficiencyFull load charging efficiency is higher than most others in the industry by using UXR moduleStandby energy savingLow standby power consumption,reducingoperating costsApplicable to all types of vehiclesOutput power 100-1000V,applicable to all types ofelectric vehiclesApplication scenariosIt is compatible with the design of DCcharging module and has a wider application scenariosEfficient and stable heat dissipation
Unique air duct design,small impedance,strongcompression capacity, high heat dissipation efficiency,stable and reliableSimple structure and layoutSimple and elegant structure layout,strongand weak AC-DC separation, smallsize,smalloccupationofspaceWaterproofand dustproofElectrical and air duct are completelyisolated,physical structure ofwaterproof design,high density dust netUl customizationCustomized appearanceVIN intelligent recognitionVIN identification ensures intelligent chargingFlexible power distributionThe power can be flexibly dispatched according to the needs ofeach terminal's demand.
Excellent noise reductionFolding air conditioning segmentation design,greatly increase the area of noise reduction
